Feature:
◆Modern stylish appearance and exquisite design,firm construction and precise craftsmanship;
◆"U"shaped rails 3"x1 1/4"tapped both front and rear with EIA compliant RMS space;
◆According to 19” international standard, suitable for different equipments with different depths;
◆Meets or exceeds EIA-310D standards
◆Base with perforated holes for floor anchoring;
◆All the mounting posts with U mark;
◆Adjustable depth from 24”-36” with 1/2”;
◆Fixed shelf ,sliding shelf, keyboard shelf, cable manager, PDU and other accessories are on your option;
◆Various heights from 16u to 47u;
◆Flat package for easily carrying and saving container space,
Standard:
Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491;PART1,DIN41494;PART7,GB/3047.2-92 standard
Material:
Aluminum
SPCC cold rolled steel
16U-22U Static Loading Capacity: 300kg
25U-45U Static Loading Capacity: 600kg
Degree of Protection:
IP20
Thickness of Aluminum:
All the aluminum part 4.5mm
Thickness of Adjustable bars:(STEEL)
SPCC 2.5mm
Surface treatment:
phosphoric treatment, powder spraying
Colors option:
RAL9004/9005 BLACK
RAL7035 COMPUTER GRAY
RAL9010 CREAM WHITE
Main Specification (mm)
|
Model No.
|
U
|
width*depth*height(mm)
|
|
TPRS-035716A
|
16U
|
515*(24“－36”)*854
|
|
TPRS-035720A
|
20U
|
515*(24”－36“)*1032
|
|
TPRS-035728A
|
28U
|
515*(24“－36”)*1388
|
|
TPRS-035745A
|
45U
|
515*(24“－36“)*2143
|
