Feature:
◆Modern stylish appearance and exquisite design,firm construction and precise craftsmanship;
◆"U"shaped rails 3"x1 1/4"tapped both front and rear with EIA compliant RMS space;
◆According to 19"international standard, suitable for different equipments with different depths;
◆Meets or exceeds EIA-310D standards
◆The front section is reversible for right or left side opening;
◆The rear section can be easily separated from the mounting section;
◆Fixed shelf ,sliding shelf, keyboard shelf, cable manager, PDU and other accessories are on your option;
◆Various heights from 12u to 25u;
◆Fixing the back panel directly and easily onto the wall;
◆Flat package for easily carrying and saving container space.
Standard:
Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491;PART1,DIN41494;PART7,GB/3047.2-92 standard
Material:
SPCC cold rolled steel
12U Static Loading Capacity:30kg
20U Static Loading Capacity:40kg
25U Static Loading Capacity:50kg
Degree of Protection:
IP20
Thickness of Steel:
Mounting post 3.0mm,others 1.8mm
Surface treatment:
Degreasing, pickling, phosphoric treatment, powder spraying
Colors option:
RAL9004/9005 BLACK
RAL7035 COMPUTER GRAY
RAL9010 CREAM WHITE
Main Specification (mm)
|
Model No.
|
U
|
width*depth*height(mm)
|
Model No.
|
U
|
width*depth*height(mm)
|
|
TPRS-045412
|
12U
|
524*461*428
|
TPRS-045612
|
12U
|
524*635*428
|
|
TPRS-045420
|
20U
|
524*461*784
|
TPRS-045620
|
20U
|
524*635*784
|
|
TPRS-045425
|
25U
|
524*461*1006
|
TPRS-045625
|
25U
|
524*635*1006
|
