Feature:
◆Modern stylish appearance and exquisite design,firm construction and precise craftsmanship;
◆"U"shaped rails 3"x1 1/4"tapped both front and rear with EIA compliant RMS space;
◆According to 19” international standard, suitable for different equipments with different depths;
◆Meets or exceeds EIA-310D standards
◆Base with perforated holes for floor anchoring;
◆Fixed shelf ,sliding shelf, keyboard shelf, cable manager, PDU and other accessories are on your option;
◆Various heights from 16u to 47u;
◆Flat package for easily carrying and saving container space,
Standard:
Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491;PART1,DIN41494;PART7,GB/3047.2-92 standard
Material:
Aluminum
Static Loading Capacity: 200kg
Degree of Protection:
IP20
Thickness of Aluminum:
All the part 4.5mm
Surface treatment:
phosphoric treatment, powder spraying
Colors option:
RAL9004/9005 BLACK
RAL7035 COMPUTER GRAY
RAL9010 CREAM WHITE
Main Specification (mm)
|
Model No.
|
U
|
width*depth*height(mm)
|
|
TPRS-025716
|
16U
|
515*77*854
|
|
TPRS-025720
|
20U
|
515*77*1032
|
|
TPRS-025728
|
28U
|
515*77*1388
|
|
TPRS-025745
|
45U
|
515*77*2143
|
