Feature:
◆Welded structure, firm construction and precise craftsmanship;
◆According to 19” international standard, mounting post with adjustable design to be suitable for different equipments with different depths；
◆Tempered glass front door with rotatable lock, turning degree can be over 180°;
◆Ventilated design in the front door and the side panels for heat-cooling;
◆Cable entry on the top cover, bottom plate and back panel with knock-out plate;
◆Fan hole available on the top cover，fan installing depends;
◆Fixing the back panel directly and easily onto the wall;
◆Various heights from 6u to 18u ,depth 150mm and 300mm optional;
◆Assembled package convenient for customers.
Standard:
Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491;PART1,DIN41494;PART7,GB/3047.2-92 standard
Material:
SPCC cold rolled steel
Static Loading Capacity:
60kg
Degree of Protection:
IP20
Thickness of Steel：
Mounting post 1.5mm,others 1.0mm
Surface treatment:
Degreasing, pickling, phosphoric treatment, powder spraying
Colors option:
RAL9004/9005 BLACK
RAL7035 COMPUTER GRAY
RAL9010 CREAM WHITE
Main Specification (mm)
|
Model No.
|
U
|
width*depth*height(mm)
|
Model No.
|
U
|
width*depth*height(mm)
|
|
TPWG-026106
|
6U
|
600*150*334
|
TPWG-026306
|
6U
|
600*300*334
|
|
TPWG-026109
|
9U
|
600*150*467
|
TPWG-026309
|
9U
|
600*300*467
|
|
TPWG-026112
|
12U
|
600*150*600
|
TPWG-026312
|
12U
|
600*300*600
|
|
TPWG-026115
|
15U
|
600*150*733
|
TPWG-026315
|
15U
|
600*300*733
|
|
TPWG-026118
|
18U
|
600*150*867
|
TPWG-026318
|
18U
|
600*300*867
|
