Feature:
◆Modern stylish appearance and exquisite design，firm construction and precise craftsmanship;
◆According to 19” international standard, suitable for different equipments with different depths;
◆Adjustable feet and universal castors in the bottom are available;
◆Fixed shelf ,sliding shelf, keyboard shelf, cable manager, PDU and other accessories are on your option;
◆Various heights from 16u to 47u;
◆Flat package for easily carrying and saving container space,
Standard:
Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491;PART1,DIN41494;PART7,GB/3047.2-92 standard
Material:
SPCC cold rolled steel
Static Loading Capacity: 200kg
Degree of Protection:
IP20
Thickness of Steel:
Mounting post 2.0mm ,bottom 1.5mm, top and bottom jointing plate 1.2mm
Surface treatment:
Degreasing, pickling, phosphoric treatment, powder spraying
Colors option:
RAL9004/9005 BLACK
RAL7035 COMPUTER GRAY
RAL9010 CREAM WHITE
Main Specification (mm)
|
Model No.
|
U
|
width*depth*height(mm)
|
|
TPRS-016116
|
16U
|
600*120*844
|
|
TPRS-016128
|
28U
|
600*120*1378
|
|
TPRS-016130
|
30U
|
600*120*1466
|
|
TPRS-016135
|
35U
|
600*120*1688
|
|
TPRS-016140
|
40U
|
600*120*1911
|
|
TPRS-016147
|
47U
|
600*120*2222
|
