Feature:
◆Audio & Video rack enclosure equipped with adjustable 19” mounting posts;
◆Welded firm structure, luxurious indoor style;
◆Removable side panels with latch, easy to install;
◆High-density perforated design make a good ventilation, it helps to keep the stability of the equipment;
◆Two universal wheels and two directional wheels with brake，stop stably whenever and wherever;
◆16U and 30U on your option;
◆Assembled package convenient for customers.

Standard:
Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491;PART1,DIN41494;PART7,GB/3047.2-92 standard
Material:
SPCC cold rolled steel
Static Loading Capacity: 650kg
Degree of Protection:IP20
Thickness of Steel:
frame 2.5mm,bottom 2.0mm, shelf 1.5mm,panel 1.5mm,cable lacing bar 1.5mm, others 1.2mm
Surface treatment:Degreasing, pickling, phosphoric treatment, powder spraying
Colors option:
RAL9004/9005 BLACK
RAL7035 COMPUTER GRAY
RAL9010 CREAM WHITE


Main Specification (mm)

Model   No.	U	width*depth*height(mm)
TPAR-015616	16U	565*600*862
TPAR-015630	30U	565*600*1485
